Ubiquiti AirGrid M2 HP Point-to-Multipoint, Antenna, Radio System:
Ubiquiti AirGrid M2 HP 2.4GHz Features:
Product Model Number: AG-HP-2G16
Hi-Performance, Long Range
Completely Integrated CPE in the Feed of the Antenna
Easy Assembly(plug and play)
Feed Antenna Technology
Ubiquiti InnerFeed Technology integrates the entire radio system into the feedhorn of antenna. AirGrid M2-HP combines Ubiquiti Innerfeed and AirMax technologies to create a simple, Extremely powerful and wireless unit capable of 100+MBPS Real outdoor throughput up to 30km+ Range.
Design provides complete weatherproof performance.
Activity and signal strength LED's provided for installers.
RF and Ethernet protection Enables prolonged operation in harshest environments.
Ubiquiti AirGrid-M2-HP Point-to-Multipoint, Antenna, Radio System Specification:
AirOS
The user interface is a powerful firmware which enables hi-performance outdoor multipoint networking.
Protocol Support
Ubiquiti Channelization
Spectral Width Adjust
ACK Auto-Timing
AAP Technology
Multi-Language Support
AirView
AirGrid M2 HP Ubiquiti M products, AirView provides Advanced Spectrum Analyzer Functionality.
Waterfall:Aggregate energy over time for each frequency.
Waveform:Aggregate energy collected.
Real-time:Energy is shown real-time as a function of frequency.
Recording: Automize AirView to record and report results.
AirControl
AirControl is a powerful web based server network management application which allows operators to centrally manage entire networks of Ubiqutii devices.
Network Map,
Monitor Device Status,
Mass Firmware Upgrade,
Web UI Access,
Manage Groups of Devices,
Task Scheduling.
System Information
Processor:Atheros MIPS 24KC,400MHz
Memory:32MB SDRAM, 8MB Flash
Networking Interface:1 X 10/100 BASE-TX(Cat. 5, RJ-45)Ethernet
Compliance Information
Wireless Approvals:FCC Part 15.247, IC RS210, CE
RoHS Compliance:Yes
Physical
Enclosure Characteristics:Outdoor UV Stabilized Plastic
Mounting Kit:Pole Mounting Kit included
Power Supply:24V/0.5A POE Adapter
Power Method:Passive Power over Ethernet
Max Power Consumption:3.0 Watts
Operating Temperature:-30C to 75C
Operating Humidity:5to95% Condensing
Shock and Vibration:ETSI300-019-1.4
Weight:Feed 0.2Kg, Mount 0.65Kg, 11x14"Reflector 0.8Kg, 17x24"Reflector 1.9Kg
